BluePrint Engines Pro Series Chevy 427 C.I.D. 540 HP Base Long Block Crate Engines PS4272CT1

$7,231.00

Crate Engine, Long Block, 427 Stroker, 540 HP, 535 TQ, New Block, Aluminum Heads, 4-Bolt Mains, Chevrolet, Small Block, Each

53261 people are online viewing
Add to wishlist
Category:

Description

Overview

Brand: BluePrint Engines
Manufacturer’s Part Number: PS4272CT1
Part Type: Crate Engines
Product Line: BluePrint Engines Pro Series Chevy 427 C.I.D. 540 HP Base Long Block Crate Engines
Summit Racing Part Number: MLL-PS4272CT1
UPC: 00887753744340
Crate Engine Family: Chevy Small Block
Actual Engine Displacement: 7.0L/427
Crate Engine Cylinder Head Material: Aluminum
Engine Block Material: Cast iron
Advertised Compression Ratio: 10.0:1
Assembled: Yes
Engine Balance: Internal
Cam Style: Hydraulic roller, OE roller
Rear Main Seal Style: 1-piece
Intake Manifold Included: No
Cylinder Heads Included: Yes
Carburetor Included: No
Throttle Body Included: No
Distributor Included: No
Oil Pan Included: Yes
Valve Covers Included: Yes
Timing Cover Included: Yes
Water Pump Included: No
Harmonic Balancer Included: Yes
Flexplate Included: No
Flywheel Included: No
Air Cleaner Included: No
Spark Plugs Included: No
Spark Plug Wires Included: No
Computer Included: No
Wiring Harness Included: No
Supercharger Included: No
Remanufactured: No
Quantity: Sold individually.
Notes: Features a 4-bolt main block and a forged rotating assembly.

BluePrint Engines Pro Series Chevy 427 C.I.D. 540 HP Base Long Block Crate Engines

BluePrint Pro Series 427 c.i.d. base long block crate engines have the muscle that you need to impress. These powerhouses feature a 30-month/50,000-mile warranty and are the perfect choice for drivable and reliable high-end performance. Additionally, the BluePrint Pro Series Chevy 427 c.i.d. base crate engine assemblies are dyno-tested and include the dyno sheets.

Pro Series 427 base long blocks feature:

* 540 hp, 535 ft.-lb., compression ratio 10.0:1
* BluePrint cast iron block with 4-bolt main
–4.125 in. bore
–2-piece rear main seal
–Mechanical fuel pump provision
–Passenger side dipstick
–Drilled and tapped for clutch linkage
* Forged crankshaft and connecting rods
* Forged pistons with rings
* Internal front/internal rear balanced rotating assembly
* BluePrint aluminum cylinder heads
–64cc chamber
–2.08 in. intake/1.60 in. exhaust valves
–220cc intake/67cc exhaust runners
* Hydraulic roller cam
–.577 intake/.577 exhaust lift
–240 intake/248 exhaust duration @ .050
–112 degree lobe separation
* Ignition timing
— Initial timing 10 to16 degrees and total timing 32 to 34 degrees
* Valve covers, oil pan, and timing cover
* Harmonic balancer
